sized for 25,000 hours of B-10 life @ < 3 degree operating angle
48" balanced assemblies
SERIES |
HP @ 1800 RPM |
1350 |
|
100 |
|
135 |
|
165 |
|
250 |
|
322 |
|
1810 |
450 |
1880 |
625 |
| 1410 Series Parts Breakdown | |
| Quantity |
Part No |
| 2 |
2-0054 UJ |
| 2 |
3-2-159 Flange Yoke |
| 1 |
3-28-97 Tube Yoke |
| 1 |
3-40-1611 Splined Stub |
| 1 |
3-3-118KX Slip Yoke |
| 3x.083 Tubing | |
| 1480 Series Parts Breakdown | |
| Quantity |
Part No |
| 2 |
3-0188 UJ |
| 2 |
3-2-479 Flange Yoke |
| 1 |
3-28-537 Tube Yoke |
| 1 |
3-40-1571 Splined Stub |
| 1 |
3-3-1601KX Slip Yoke |
| 3.5x.083 Tubing | |
| 1550 Series Parts Breakdown | |
| Quantity |
Part No |
| 2 |
3-0155 UJ |
| 2 |
4-2-669 Flange Yoke |
| 1 |
4-28-307 Tube Yoke |
| 1 |
4-40-761 Splined Stub |
| 1 |
4-3-1241KX Slip Yoke |
| 3.5x.095 Tubing | |
| 1610 Series Parts Breakdown | |
| Quantity |
Part No |
| 2 |
4-0279 UJ |
| 2 |
5-2-279 Flange Yoke |
| 1 |
5-28-627 Tube Yoke |
| 1 |
5-40-1011 Splined Stub |
| 1 |
5-3-2261KX Slip Yoke |
| 3.5x.134 Tubing | |
| 1710 Series Parts Breakdown | |
| Quantity |
Part No |
| 2 |
5-0280 UJ |
| 2 |
6-2-749 Flange Yoke |
| 1 |
6-28-347 Tube Yoke |
| 1 |
6-40-541 Splined Stub |
| 1 |
6-3-2671KX Slip Yoke |
| 4.095x.180 Tubing | |
| SAE Flywheel Dimensions: | |||
SAE Clutch Size / 'Designation' |
Plate OD |
Bolt Circle |
Holes |
6.5" |
8.50" |
7.875" |
|
7.5" |
9.50" |
8.750" |
|
8" |
10.375" |
9.625" |
|
10" |
12.375" |
11.625" |
|
11.5" |
13.875" |
13.125" |
|
14" |
18.375" |
17.250" |
|
16" |
20.375" |
19.250" |
|
18" |
22.5" |
21.375" |
|
21" |
26.50" |
25.250" |
|
24" |
28.875" |
27.252" |
|
|
|
|
|
| SAE Flywheel housing dimensions | ||||
SAE # |
I. D. |
BOLT CIRCLE |
HOLES |
USED WITH SAE CLUCTH |
0 |
|
|
|
|
1 |
20.125 “ |
20.8752” |
12 |
14” |
2 |
17.625” |
18.375” |
12 |
11.5” |
3 |
16.125” |
16.875” |
12 |
11.5” |
4 |
14.25” |
15” |
12 |
8”/10” |
5 |
12.375” |
13.125” |
8 |
7.5” |
6 |
10.5” |
11.25” |
8 |
6.5” |
| SAE Flange Patterns | |||
| (rectangular patterns are 100 degrees x 80 degrees) | |||
Series |
Pilot Diameter |
Bolt Circle |
Number of Holes |
1310 |
2.375" |
2.750" |
4 |
1350 / 1410 |
2.750" |
3.750" |
4 |
1480 / 1550 |
3.750" |
4.750" |
4 |
1610 |
6.625" |
6.125" |
8 |
1710 |
7.750" |
7.250" |
8 |
1810 |
7.750" |
7.250" |
12 |
1880 |
7" |
8.250" |
8 |
| DIN Flange Patterns | |||
Series |
Pilot Diameter |
Bolt Circle |
Number of Holes |
42 mm |
62 mm |
6 |
|
47 mm |
74.5 mm |
4 |
|
57 mm |
84 mm |
6 |
|
75 mm |
101.5 mm |
8 |
|
90 mm |
130 mm |
8 |
|
95 mm |
140 mm |
8 |
|
110 mm |
155.5 mm |
8 |
|
| Adapters by Phoenix | |||
SAE Clutch Size |
Plate OD |
Driveline |
Part Number |
6.5" |
8.5" |
1410 |
26-4001 |
6.5" |
8.5" |
1310 |
26-4011 |
7.5" |
9.5" |
1410 |
26-4002 |
7.5" |
9.5" |
1310 |
26-4012 |
8" |
10.375" |
1410 |
26-4003 |
8" |
10.375" |
1310 |
26-4013 |
10" |
12.375" |
1550 |
26-4004 |
10" |
12.375" |
1410 |
26-4014 |
10" |
12.375" |
1550 / 1410 |
26-4114 |
11.5" |
13.875"" |
1550 |
26-4005 |
11.5" |
13.875" |
1550 / 1410 |
26-4015 |
11.5" |
13.875" |
1610 |
26-4006 |
11.5" |
13.875" |
1710 |
26-4008 |
14" |
18.375" |
1610 |
26-4007 |
14" |
18.375" |
1710 |
26-4009 |
|
|
|
|
