| 6 Series * Horse Power: 16 @ 540 RPM 30 @ 1000 RPM |
|
| 6 Series Universal Joints * (A)0.969 x (B)2.312 w/ 1.453 inside lock |
|
| Part No |
Detail |
| 1-1475 |
|
| 200-0600 |
|
| |
|
|
| 6 Series Bar Yokes |
|
| Rectangular Bore |
| Bore |
Part No |
Length |
Detail |
| .750 x .875 |
300-0600 |
|
|
| |
16-6129 |
|
|
| 1.00 x 1.125 |
16-6131 |
|
|
| |
700-0600 |
|
|
| Splined Bore |
| Bore |
Part No |
Length |
Detail |
| 1.00 - 15 |
302-0600 |
2.250 |
with shield groove |
| |
301-0600 |
2.375 |
without shield groove |
|
| 6 Series Center Yokes |

|
| Part No |
Length |
| 16-8600 |
2.5" c-c / 18 degrees |
| |
|
|
| 6 Series Tube Yokes |
|
| Tube Size |
Part No |
Length |
| 1.50x.065 |
701-0600 |
3.125 w/ groove |
| |
702-0600 |
2.00 wo/ groove |
| |
16-6132 |
|
|
| 6 Series Sleeves |
|
| Rectangular Bore |
| Bore |
Tube |
Part No |
Length |
| 1.750x.875 |
1.50x.065 |
510-0600 |
|
| 1.750x.875 |
1.50x.065 |
53-0635 |
4.00 oal |
| Splined Bore |
| 1.00 - 15 |
1.50x.065 |
510-0615 |
|
|
| |
| 6 Series Shafting |
|
| Shaft Size |
Part No |
Detail |
| .750x.875 |
400-1214 |
|
| |
73-0750 |
|
| 1.00x1.125 |
600-1618 |
|
| |
70-1001 |
|
| 1.00 -15 spline |
404-1615 |
|
|
| 6 Series Quick Disconnect Yokes |

100-0606
|
| Spline |
Part No |
Length |
Detail |
| .981 -10 |
101-0610 |
3.125 |
|
| |
105-0610 |
2.750 |
|
| Spline |
Part No |
Length |
Detail |
| 1.00 - 15 |
101-0615 |
3.125 |
|
| |
105-0615 |
2.750 |
|
| |
16-0615 |
2.812 |
|
| Spline |
Part No |
Length |
Detail |
| 1.375 - 6 |
100-0606 |
3.875 |
|
| |
102-0606 |
|
|
| |
16-6409 |
3.562 |
|
| Spline |
Part No |
Length |
Detail |
| 1.375 - 21 |
100-0621 |
|
|
| |
102-0621 |
|
|
| |
16-0621 |
|
|
| |
|
|
|
|
| 6 Series Spline Bored End Yokes |
|
| Bore - Splines |
Part No |
Length |
Detail |
| |
|
|
|
| .875 - 20 |
06011-1000 |
|
|
| 1.00 -15 |
06011-1001 |
|
pin hole |
| |
|
|
|
| 1.125 - 6 |
801-0618 |
|
|
1.375 - 6 |
801-0606 |
|
|
| |
|
|
|
| |
|
|
|
| |
|
|
|
|
| 6 Series Clamp Yokes |
|
| Bore |
Part No |
Length |
Detail |
| |
|
|
|
| 1.00 - 15 spline |
807-0615 |
|
|
| |
|
|
|
| .875R x .187k |
807-0614 |
|
|
| 1.00R x .250k |
807-0616 |
|
|
| |
|
|
|
| |
|
|
|
|
| 6 Series Round Bore End Yokes |
|
| Bore - keyway |
Part No |
Length |
Detail |
| .625 x .187 |
16-6210 |
2.50 |
|
| |
800-0610 |
|
|
| .750 x .187 |
16-6111 |
|
|
| |
800-0612 |
|
|
| .812 x .250 |
16-6112 |
|
|
| |
800-0613 |
|
|
| .875 x .250 |
16-6213 |
|
|
| |
800-0614 |
|
|
| .937 x .250 |
16-6114 |
|
|
| |
800-1615 |
|
|
| 1.00 x .250 |
16-6215 |
|
double key |
| |
806-0616 |
|
double key |
| 1.125 x .250 |
16-6216 |
|
double key |
| |
806-0618 |
|
double key |
| 1.187 x .250 |
16-6217 |
|
double key |
| |
806-0619 |
|
double key |
| 1.250 |
16-6218 |
|
double key |
| |
806-0620 |
|
double key |
| |
|
|
|
|
| 6 Series Yokeshaft |
|
| Bore |
Part No |
Detail |
| 1.00 - 15 |
16-1615 |
5.375" c-e |
| |
106-0615 |
5.375 |
| |
|
|
|
| 6 Series Shielding |
 |
| Shield |
Shield Bearing Kit |
Detail |
| 69-0648 |
56-0600 |
|
| 900-2548 |
921-0600 |
Standard Shield |
|
| |
