Walterscheid K64 Automatic Cutout Clutches

More popular than ever thanks to a reliable mechanism that requires almost no maintenance

Tired of changing shear bolts? Need a clutch set to a specific setting?

The K64 Automatic / Cam / Cutout Clutch is THE TICKET !

...

Go to specifications page

Part Number Series Model Diameter Splines Length c-e Torque

193334 2400 K64/2*Triolete 1.750 6 1800nm

694088 2400 K64/22 1.375 6 2000nm

135454 2400 K64/22 1.375 21 1500nm

135455 2400 K64/22 1.75 6 1800nm

Part Number Series Model Diameter Splines Length c-e Torque

134467 2500 K64/24 1.750 20 3500nm

LAF20250MDAL67 2500 K64 1.750 20 2500nm

LAR20250MDAL67 2500 K64 combo 1.75 20 2500nm

LAR34250MDAL67 2500 K64 combo 1.75 6 2500nm

135416 2500 K64/24 1.375 6 2700nm

135362 2500 K64/24 1.75 6 2700nm

135986 2500 K64/24 1.750 20 2700nm

Part Number Series Model Diameter Splines Length c-e Torque

LAR34350MDAT09 2600 PRO K64 combo 1.75 6 3500nm

694175 2600 PRO K64/24L 1.750 20 3800nm

135415 2600 PRO K64/24R 1.750 6 4000nm

135808 2600 PRO K64/24R 1.750 20 3800nm

138041 2600 PRO K64/24R 1.750 20 4500nm

Part Number Series Model Diameter Splines Length c-e Torque

136716 2700 K64/24L 1.750 6 9.125 4500nm

135767 2700 K64/24R 1.750 6 9.125 4500nm

135865 2700 K64/24R 1.750 20 9.125 4500nm

Part Number Series Model Diameter Splines Length c-e Torque

LAX38200MDA EK EK64/22 1.375 6 138BC 2000nm

LAX20290MDA EK EK64/22 1.75 20 138BC 2900nm

LAX34290MDA EK EK64/22 1.75 6 138BC 2900nm

129875 EK EK64/24 1.750 20 138BC 2500nm

138772 EK EK64/24 1.750 20 138BC 4000nm

136029 EK EK64/24 1.750 6 138BC 3800nm

Walterscheid EK64 Automatic Cutout Clutches

Part Number Series Model Diameter Splines Bolt Circle Torque

LAX38200MDA EK EK64/22 1.375 6 138BC 2000nm

LAX20290MDA EK EK64/22 1.75 20 138BC 2900nm

LAX34290MDA EK EK64/22 1.75 6 138BC 2900nm

129875 EK EK64/24 1.750 20 138BC 2500nm

138772 EK EK64/24 1.750 20 138BC 4000nm

136029 EK EK64/24 1.750 6 138BC 3800nm

Walterscheid Flanges to fit EK64 Automatic Cutout Clutches

Part Number Series Pilot Bolt Circle Hole Dia No of Holes

320699 2400 98 mm 138 mm 12 mm 6

317807 2500 98 mm 138 mm 12 mm 6

334661 2600 98 mm 138 mm 12 mm 12

170049 2700 98 mm 138 mm 12 mm 12
